Custom 3D Bed Builder and Designer

This online bed designer helps you mock up a single or double bed in seconds. Slide widths, lengths, leg heights and panel thicknesses then watch the 3D model and drawing update in real time. No heavy settings, just practical controls and immediate visual feedback. Perfect for makers, DIYers and anyone who wants to order the right material without guesswork.

How to get started

1. Pick mattress size. Choose a standard size so your frame matches the mattress snugly.
2. Set overall dimensions. Enter bed width and length, then set leg height and box height to find mattress position and total bed height.
3. Adjust thickness and style. Change sideboard and leg thickness to see how the silhouette and material estimates change.
4. Choose headboard and color. Try different headboard styles to check visual balance and how much wall it covers.
5. Review metrics. The plan and side views show final sizes in inches. The summary table lists volume, board linear footage, estimated weight and usable mattress area.

Controls explained

The interface uses paired controls for most parameters. Use the slider for fast changes and the number field for precision. Color pickers apply to the frame and mattress. The headboard selector swaps shapes instantly. Buttons let you reset to defaults or download a PNG of the 3D scene and drawings.

• Width / Length set the mattress footprint. Use standard mattress sizes for easy fitting.
• Leg height changes the underbed clearance. Taller legs give airiness but check stability.
• Box height is the depth of the frame that holds the mattress.
• Frame and leg thickness feed into material volume and the look of the bed.
• Headboard type switches between flat, rounded, slatted and paneled heads.

Practical design tips

• For standard mattress fit use common US mattress sizes listed below.
• Panels and slats typically work well at three quarter inch to seven eighths inch. That matches common plywood and laminated board thickness.
• Legs should be at least 1.25 to 2 inches thick for solid support in simple frames.
• For widths 60 inches and more add a center support rail and at least one center leg under the rail.
• Slat spacing has a direct impact on mattress life. Keep slat gaps under 3 inches for foam mattresses and under 4 inches for innerspring models.
• Leave 0.25 to 0.5 inches clearance on each side of the mattress for easy fitting and bedding tuck.
• Pre-drill pocket holes or use metal corner brackets to make assembly fast and rigid.
• Use corrosion resistant screws and glue where necessary for a durable frame.

Reference tables — US sizes and recommendations

Measure the board dimensions available at your lumberyard and enter them into the tool. The summary will show how many boards you need plus a recommended waste allowance. For cut optimization order longer boards to reduce joints and keep grain continuous on visible panels. If painting, use plywood with a smooth face. For stain use hardwood or veneered plywood for better finishes.

Quick build sequence

1. Cut long side panels and top rails first to minimize waste.
2. Assemble the frame dry with clamps and test fit the mattress and slats.
3. Install center support if the bed is queen size or larger.
4. Finish sand all exposed edges then apply your chosen finish.
5. Final assembly using screws and glue or pocket joinery for hidden fasteners.

Safety and usability checks

• Check for sharp edges and round corners where people might bump.
• Confirm load carrying of slats and center support before mounting a heavy mattress.
• Test the bed for wobble and tighten fasteners after a few days of use.

Examples and quick conversions

Example for a queen frame: set Width to 60 inches and Length to 80 inches. Use 3/4 inch panels for sides and slats spaced at 2.5 inches. Add a center rail with two legs. This setup gives stable support for most mattress types and stays economical on boards.

Export and download

Use the Download button to capture a high resolution PNG of the 3D model and plans. Save the image to take to the shop for precise cutting or to share with a fabricator.
